Inheritance diagram for OMF::OMF86Format::CommentRecord:

Classes
class	EmptyCommentRecord

class	GenericCommentRecord

class	TextCommentRecord

Public Types
enum	comment_class_t : uint8_t { Translator = 0x00 , IntelCopyright = 0x01 , LibrarySpecifier = 0x81 , MSDOSVersion = 0x9C , MemoryModel = 0x9D , DOSSEG = 0x9E , DefaultLibrarySearchName = 0x9F , OMFExtension = 0xA0 , NewOMFExtension = 0xA1 , LinkPassSeparator = 0xA2 , LIBMOD = 0xA3 , EXESTR = 0xA4 , INCERR = 0xA6 , NOPAD = 0xA7 , WKEXT = 0xA8 , LZEXT = 0xA9 , Comment = 0xDA , Compiler = 0xDB , Date = 0xDC , TimeStamp = 0xDD , User = 0xDF , DependencyFile = 0xE9 , CommandLine = 0xFF }

Public Member Functions
	CommentRecord (comment_class_t comment_class=comment_class_t(0))

virtual void	ReadComment (OMF86Format omf, Module mod, Linker::Reader &rd, uint16_t comment_length)=0

virtual uint16_t	GetCommentSize (OMF86Format omf, Module mod) const =0

virtual void	WriteComment (OMF86Format omf, Module mod, ChecksumWriter &wr) const =0

void	ReadRecordContents (OMF86Format omf, Module mod, Linker::Reader &rd) override

uint16_t	GetRecordSize (OMF86Format omf, Module mod) const override

void	WriteRecordContents (OMF86Format omf, Module mod, ChecksumWriter &wr) const override

Public Member Functions inherited from OMF::OMFFormat::Record< RecordTypeByte, FormatType, ModuleType >
	Record (RecordTypeByte record_type=RecordTypeByte(0))

offset_t	RecordEnd () const

virtual void	ReadRecordContents (FormatType omf, ModuleType mod, Linker::Reader &rd)=0
	Reads the record contents, except for the type, length and checksum.

virtual uint16_t	GetRecordSize (FormatType omf, ModuleType mod) const =0
	Calculates the required bytes to write the record, might be less than record_length.

virtual void	WriteRecordContents (FormatType omf, ModuleType mod, ChecksumWriter &wr) const =0
	Writes the record contents, except for the type, length and checksum.

virtual void	WriteRecord (FormatType omf, ModuleType mod, Linker::Writer &wr) const
	Writes the full record.

virtual void	CalculateValues (FormatType omf, ModuleType mod)
	Updates all fields that will be used for writing an OMF module, should be called before output.

virtual void	ResolveReferences (FormatType omf, ModuleType mod)
	Resolves any fields read from an OMF module, should be called after inpnut.

virtual void	DumpAddFields (Dumper::Dumper &dump, Dumper::Region &region, const FormatType omf, const ModuleType mod, size_t record_index) const

virtual void	Dump (Dumper::Dumper &dump, const FormatType omf, const ModuleType mod, size_t record_index) const

bool	Is32Bit (FormatType *omf) const
	Records are 32-bit if the least significant bit of their record type is set (only meaningful for OMF86Format)

size_t	GetOffsetSize (FormatType *omf) const
	The number of bytes in an offset appearing inside the record, 2 for 16-bit records, 4 for 32-bit records (only meaningful for OMF86Format)

Static Public Member Functions
static std::shared_ptr< CommentRecord >	ReadCommentRecord (OMF86Format omf, Module mod, Linker::Reader &rd, uint16_t record_length)

Public Attributes
bool	no_purge

bool	no_list

comment_class_t	comment_class

Public Attributes inherited from OMF::OMFFormat::Record< RecordTypeByte, FormatType, ModuleType >
offset_t	record_offset
	Offset of record within the file.

uint16_t	record_length
	Length of record body file, excluding the type byte and 2-byte length field.

RecordTypeByte	record_type
	A byte value identifying the type of record.

The documentation for this class was generated from the following files:

src/format/omf.h
src/format/omf.cc
